MOTO GUZZI GRISO Use And Maintenance Book

use and maintenance Griso R
32
Engine oil pressure warning light
Comes on when the ignition switch is set to " " with the engine stopped as a lamp test.
If the light does not come on in this phase, contact a Moto Guzzi Authorized Dealer.
If the engine oil pressure warning light remains on after the
start or comes on during the normal operation of the engine, this
means that the engine oil pressure in the circuit is insufficient. In this case, stop the
engine immediately and contact a Moto Guzzi Authorized Dealer.
Alarm led
W
orks as general alarm warning (excluded the engine oil pressure one) and gear shift indicator.
If the LED " " stays on after the engine is started or comes on
during normal engine operation, it means that the control unit has
detected a failure; immediately contact a Moto Guzzi Authorized Dealer.
If LED warning light " " flashes when the vehicle is off it means that immobiliser or optional
antitheft alarm have been enabled.
Turn indicator warning light Blinks when the direction indicators are on.
High beam warning light Comes on when the high beam bulbs are on or when the headlight signaller is operated.
Low fuel warning light
Comes on when the quantity of fuel left in the tank is approx. 0.87 US gal. (3.3
b ).
In this case, top up as soon as possible, see page 28 (FUEL).
Neutral indicator warning light Comes on when the gear is in neutral.
Side stand down light Turns on when the side stand is down.
Description Function
CAUTION
CAUTION
GUZum_griso1100#06_#USA.book Page 32 Tuesday, March 21, 2006 2:43 PM

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
