MOTO GUZZI GRISO Use And Maintenance Book

use and maintenance Griso R
44
The tool kit includes:
– 4, 5 mm bent Allen wrenches (1);
– 10 - 13 mm double fork wrench (2);
– 21 - 22 mm socket wrench (3);
– double-ended cross-head/flat-blade
screwdriver (4);
– fuse removing tool (5);
– tool box (6).
LUGGAGE ANCHOR POINTS
It is possible to fix a small luggage to the
seat rear end, it can be positioned using
elastic bands to be secured to the four
elements (10).
Maximum allowed weight: 11 lb (5 kg).
WARNING
Carry small luggage only and make sure
it is fastened securely.
6
3
5
4
2
1
10
GUZum_griso1100#06_#USA.book Page 44 Tuesday, March 21, 2006 2:43 PM

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
