MOTO GUZZI GRISO Use And Maintenance Book

33
use and maintenance Griso R
MULTIFUNCTION COMPUTER
When you turn the ignition key to " ", the
following instrument panel lights will turn
on for 2 seconds:
- the "GRISO" logo
- all warning lights
- backlighting
Rev counter index (1) moves to maximum
value, as set by the user.
After 2 seconds, all instruments will briefly
show the current values of the
corresponding parameters.
The display shows the following standard
settings:
– speed (zone a)
– clock (zone B)
– odometer (zone C)
– ambient temperature (zone D)
– on-board computer and accessories
functions (zone E)
CONTROLS
2) Switch with three positions: TRIP1 /
TRIP2 / MODE
3) SET button; briefly press it to scroll the
functions in the menus, press for
several seconds to confirm selected
option.
TRIP 1 AND 2
In TRIP 1 and 2 the data concerning trip 1
and 2 are shown.
Indication of displayed trip meter is on the
right, at the bottom.
Set selector (2) to the position
corresponding to TRIP configuration to be
displayed (TRIP 1 or TRIP 2).
At the bottom (F) are the following data:
–TRIP METER
–TRIP TIME
– FUEL CONSUMPTION
– MAXIMUM SPEED
– AVERAGE SPEED
Briefly press SET (3) to toggle between
these parameters. Press it for several
seconds to reset all data from selected
TRIP meter.
B D
A
C
E
1
2
3
TRIP METER
TRIP TIME
FUEL CONSUMPTION
MAXIMUM SPEED
AVERAGE SPEED
GUZum_griso1100#06_#USA.book Page 33 Tuesday, March 21, 2006 2:43 PM

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
