MOTO GUZZI GRISO Use And Maintenance Book

57
use and maintenance Griso R
CAUTION
If the engine oil pressure LED “ ” and
the icon “ SERVICE” come on during
engine normal operation, it means that
the engine oil pressure sensor is faulty.
If so, check engine oil level, see page 56
(CHECKING AND TOPPING UP ENGINE
OIL LEVEL). If insufficient, immediately
stop the engine and top up. Have the
system checked by your Moto Guzzi
Authorized Dealer.
CAUTION
Proceed with care.
Do not spill the oil!
Take care not to smear any component,
the area in which you are working and
the surrounding area. Carefully remove
any trace of oil.
In case of leakage or malfunction,
contact a Moto Guzzi Authorized
Dealer.
Periodically check the engine oil level, see
page 76 (CHECKING AND TOPPING UP
ENGINE OIL LEVEL).
To change engine oil, see page 72
(SCHEDULED MAINTENANCE CHART)
and page 76 (CHECKING AND TOPPING
UP ENGINE OIL LEVEL).
NOTE Use high quality oil, see page 106
(LUBRICANT CHART).
ADJUSTING THE FRONT BRAKE
LEVER AND THE CLUTCH LEVER
The grab distance of the lever (1) [distance
from the grip (2)] can be adjusted by
rotating the adjuster (3).
Positions “1” and “4” correspond to an
approximate lever-handgrip distance
respectively of 105 and 85 mm.
Positions “2” and “3” correspond to
intermediate distances.
u H Push the lever (1) forward and turn dial
(3) until the required number matches
the arrow.
3
2
1
1
2
3
4
GUZum_griso1100#06_#USA.book Page 57 Tuesday, March 21, 2006 2:43 PM

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
