31
use and maintenance Griso R
INSTRUMENTS AND INDICATORS TABLE
When the ignition key is turned to " " with the engine stopped, all warning lights come on for a LED check-up and go out after three
seconds. If one or more warning lights do not come on at this stage, contact a Moto Guzzi Authorized Dealer.
Description Function
Multifunction
digital display
Speedometer (km/h -
MPH)
Displays current, average or maximum riding speed (in kilometres or miles) depending on
presetting, see page 33 (MULTIFUNCTION COMPUTER).
Odometer
(KM - Mi)
Displays partial or total Km/miles run, see page 33 (MULTIFUNCTION COMPUTER).
Ambient
temperature (°C/°F)
Displays ambient temperature, the value is shown in the top right corner of the display. When
temperature is close to 3° C (37 °F) the ice symbol should be displayed. Range in °C or °F is
selected through the display, see page 33 (MULTIFUNCTION COMPUTER).
Clock Displays time (hour and minutes) as preset, see page 33 (MULTIFUNCTION COMPUTER).
Battery voltage V
BATT
Displays the battery voltage in Volts, see page 33 (MULTIFUNCTION COMPUTER).
Lap timer Displays the different lap times, as preset, see page 33 (MULTIFUNCTION COMPUTER).
Diagnosis
In case a serious failure is detected, one that might jeopardize the vehicle or the rider's safety,
the panel will show an icon indicating the failure cause (such as: oil pressure , maintenance
intervals ).
If the wording " SERVICE" appears during normal engine
operation, it means that the ECU or the instrument panel have
detected a failure. In most cases, the engine will keep running, although giving less
performance. Immediately contact a
Moto Guzzi Authorized Dealer.
Revolution counter rpm
Indicates the number of revolutions of the engine per minute.
Never exceed the engine max. speed rate, see page 48 (RUNNING-
IN).
Continued X
CAUTION
CAUTION
GUZum_griso1100#06_#USA.book Page 31 Tuesday, March 21, 2006 2:43 PM
