Motorola APX NEXT

No. Description
3 Push-to-Talk (PTT) Button
4 Touch Screen
5 Middle Side (1-Dot) Programmable Feature Button
6 Lower Side (2-Dot) Programmable Feature Button
7 Display Sleep/Wake (Short Press)
Home Button (Long Press)
8 Battery Latch
Table 2: Rear View Description
No. Description
9 RF Antenna
10 Concentric Programmable Switch (2-position)
11 Channel Selector (16-position)
12 On/Off and Volume Control Knob
13 High Dynamic Range (HDR) Mic 2
14 Speaker Grille (3-Dot) Programmable Feature Button
15 Speaker
16 NFC Antenna
17 Battery
18 Charging Contacts
19 Accessory Connector
Table 3: Top View Description
No. Description
20 Status LED
21 ABC Programmable Switch (3-position)
22 Top Display
23 Top (Orange) Button
