Chapter 4
Getting Started
This section provides instructions to prepare your radio for use.
4.1
Attaching and Removing the Battery
The radio notifies you if it detects a non-Motorola Solutions battery when it is powering up, charging, or
removed from the charger.
Attaching the Battery
Procedure:
• To attach the battery, align the battery with the bottom rails on the back of the radio. Slide the
battery into the radio frame until the side latches click into place.
Removing the Battery
Procedure:
• To remove the battery, perform the following actions:
a. Press the latches on both sides.
b. Pull the battery away from the radio.
MN005642A01-AN
Chapter 4 : Getting Started
24
