4 - 8 MC3090Z RFID Mobile Computer Integrator Guide
Post-Filter
To select post-filter settings, select Operations > Filter > Post-Filter.
Figure 4-11
Post Filter Window
This window includes the following fields:
•
Match Pattern - Select the tag pattern to match (A, B, both, or neither).
•
Memory Bank - Select the memory bank.
•
Offset - The first (msb) bit location of the specified memory bank against which to compare the tag mask.
•
Bank Data
•
Tag Mask - The pattern against which to compare the specified memory bank.
Access Filter
To select filter settings to apply to tags, select Operations > Filter > Access Filter.
Figure 4-12
Post Filter Window
See Post-Filter for descriptions of the window fields.
