decrement the timer prescaler. The maximum frequency of a signal that can
be
recognized by the
TIMER pin logic
is
dependent
on
the parameter labeled
tWL
tWH. The pin logic that recognizes the
high state
on
the pin must also recognize the low state
on
the pin
in
order to
"re-arm"
the internal
logic.
Therefore, the period
can
be
calculated
as
follows (assumes 50/50 duty cycle for a given
period):
tcyc x 2
+
250
ns
= period =
-f
1
req
The period
is
not simply
tWL
+ tWH. This computation
is
allowable, but it
does
reduce the maxi-
mum
allowable frequency by defining
an
unnecessarily longer period
(250
nanoseconds times two).
When the phase
two
signal
is
used
as
the source, it
can
be
gated by
an
input applied to the TIMER
input pin allowing the user to easily perform pulse-width measurements. The source
of
the clock in-
put
is
one of the
mask
options that
is
specified before manufacture
of
the MCU.
NOTE
For ungated phase
two
clock input to the timer prescaler, the
TI
M
ER
pin should
be
tied to
VCC·
A prescaler option, divide by 2n,
can
be
applied to the clock input that extends the timing interval
up to a maximum
of
128
counts before decrementing the counter. This prescaling
mask
option
is
also specified before manufacture. To avoid truncation errors, the prescaler
is
cleared when bit 3 of
the timer
control register
is
written
to
a logic one (this bit always
reads
a logic zero).
The timer continues to count past zero,
falling through to
$FF
from
$00
and then continuing the
countdown. Thus, the counter
can
be
read
at any time by
readin~
the timer data register (TDR).
This
allows a program to determine the length of time since a timer interrupt
has
occurred,
and
not
disturb the counting process.
At
power up or reset, the prescaler and counter
are
initialized with
all
logic ones; the timer interrupt
request bit (bit
7)
is
cleared and the timer interrupt
mask
bit (bit
6)
is
set.
S.2 MC680SR3/MC680SU3 TIMER CIRCUITRY
The timer circuitry for the
MC6805R31
MC6805U3 microcomputers
is
shown
in
Figure
5-2.
The timer
contains a
single 8-bit software programmable counter with 7-bit software selectable prescaler. The
counter
may
be
preset under program control
and
decrements toward zero. When the counter
decrements to zero, the timer interrupt request bit, i.e., bit 7 of the timer
control register (TCR),
is
set. Then
if
the timer interrupt
is
not masked, i.e., bit 6
of
the
TCR
and the I bit
in
the condition
code register
are
both cleared, the processor receives
an
interrupt. After completion
of
the current
instruction, the processor proceeds to store the appropriate registers
on
the stack, and then fetches
the timer interrupt vector from
locations
$FF8
and
$FF9
in order to begin servicing the interrupt.
The counter continues to count after it
reaches
zero, allowing the software to determine the num-
ber
of
internal or external input clocks since the timer interrupt request bit was set. The counter may
be
read
at any time by the processor without disturbing the count. The contents
of
the counter
become
stable prior to the
read
portion
of
a cycle
and
do not change during the
read.
The timer in-
terrupt request bit remains set
until cleared
by
the software. If a write occurs before the timer inter-
rupt
is
serviced, the interrupt
is
lost.
TCR7
may also
be
used
as
a scanned status bit
in
a non-
interrupt mode
of
operation
(TCR
=
1).
5-2
