Getting Started 1 - 7
Charging Spare Batteries
Use the following three accessories to charge spare batteries:
•
Single Slot Serial/USB Cradle
•
Four Slot Spare Battery Charger
•
UBC Adapter.
To charge a spare battery:
1. Ensure the accessory used to charge the spare battery is connected to the appropriate power source (see
Chapter 2, Accessories for setup information).
2. Insert the spare battery into the accessory’s spare battery charging slot with the charging contacts facing down
(over the charging pins) and gently press down on the battery to ensure proper contact.
3. The battery starts to charge automatically. The amber charge LED on the accessory lights to show the charge
status. See Chapter 2, Accessories for charging indications for the accessory.
The battery usually fully charges in less than four hours.
Removing the Main Battery
To remove the main battery:
1. Prior to removing the battery, press the red Power button to place the mobile computer in the suspend mode.
2. Simultaneously press both primary battery releases. The battery partially ejects from the mobile computer.
3. Pause 3-4 seconds while the mobile computer performs battery removal shutdown.
4. Press the secondary battery release, on top of the battery, and slide the battery out of the mobile computer.
Figure 1-3
Removing the Main Battery
Primary Battery Releases
Secondary Battery
Release
