Technical Specifications
A - 7
Accessory CAM and MSR Pin-Outs
Figure A-2
CAM and MSR Serial Connector
T
able A-4
CAM and MSR
Serial Connec
tor Pin-ou
ts
Pin
Signal
1
USB_5V_DET
2
USB_D_MINUS
3
USB_D_PLUS
4G
N
D
5G
N
D
6
PWR_EXT_OU
T
7
CRADLE_DET
*
8D
S
R
9D
C
D
10
TXD
11
C
T
S
12
DTR
13
RI
14
RTS
15
RXD
88
90
