Page #21 background image
18
10-2. Function Description
Unit
Status
Condition
Dry contact port:
NO&C
NC&C
Power
Off
Unit is off and no output is powered.
Open
Close
Power On
Battery voltage is lower than setting
battery cut-off discharging voltage
when grid is available.
Close
Open
Battery voltage is lower than setting
battery cut-off discharging voltage
when grid is unavailable.
Close
Open
Battery voltage is higher than below 2
setting values:
1. Battery re-discharging voltage
when grid is available.
2. Battery re-discharging voltage
when grid unavailable.
Open
Close
You can set the related parameters in software. Refer to below chart:
