14. Operation
14-1. Interface
The operation LCD panel, shown in the chart below, includes four touchable function
keys and a LCD display to indicate the operating status and input/output power
information.
NOTICE: To accurately monitor and calculate the energy generation, please calibrate
the timer of this unit via software every one month. For the detailed calibration, please
check the user manual of bundled software.
14-2. LCD Information Define
Touchable
function keys
LCD display
