18. Specifications
MODEL
MPI 12KW WP
MPI 15KW WP
RATED POWER
12000 W
15000 W
PV INPUT (DC)
Maximum DC Power
16000 W
16000 W
Nominal DC Voltage
720 VDC
Maximum DC Voltage
1000 VDC
Working DC Voltage Range
300 VDC ~ 1000 VDC
Start-up Voltage / Initial Feeding
Voltage
320 VDC / 350 VDC
MPP Voltage Range / Full Load
MPP Voltage Range
350 VDC ~ 950 VDC /
348 VDC ~ 900 VDC
350 VDC ~ 950 VDC /
348 VDC ~ 900 VDC
Maximum Input Current
26A + 26A
Isc PV (absolute maximum)
30 A
Max. inverter back feed current
to the array
0 A
GRID OUTPUT (AC)
Nominal Output Voltage
230 VAC (P-N) / 400 VAC (P-P)
Output Voltage Range
184 - 265 VAC per phase
Output Frequency Range
47.5 ~ 51.5 Hz or
59.3~ 60.5Hz
Nominal Output Current
17.4A per phase
21.7A per phase
Inrush Current/Duration
22 A per phase / 20ms
Maximum Output Fault
Current/Duration
66 A per phase / 1ms
Maximum output Overcurrent
Protection
66 A per phase
Power Factor Range
0.9 lead – 0.9 lag
AC INPUT
AC Start-up Voltage
120-140 VAC per phase
Auto Restart Voltage
180 VAC per phase
Acceptable Input Voltage Range
170 - 290 VAC per phase
Nominal Frequency
50 Hz / 60 Hz
AC Input Power
12KVA/12KW
15KVA/15KW
Maximum AC Input Current
40 A
Inrush Input Current
40 A / 1ms
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
230 VAC (P-N) / 400 VAC (P-P)
Output Frequency
50 Hz / 60 Hz (auto sensing)
Output Waveform
Pure sine wave
Output Power
12KVA/12KW
15KVA/15KW
Efficiency (DC to AC)
91%
BATTERY & CHARGER (Lead-acid/Li-ion)
DC Voltage Range
40 – 62 VDC
Nominal DC Voltage
48 VDC
Maximum Battery Discharging
Current
330 A
412 A
Maximum Charging Current
250 A
300 A
GENERAL
PHYSICAL
Dimension, D X W X H (mm)
255 x 660 x 750
Net Weight (kgs)
70
73
INTERACE
