MPP Solar MPI 12KW WP User Manual

37
LIb-protocol compatible
battery
Select “LIb” if using Lithium
battery compatible to Lib
protocol. If selected,
programs of4, 7, 8and 9 will
be automatically set up. No
need for further setting.
3
𝑟𝑑
party Lithium battery
If selected, programs of 4, 7,
8 and 9 will be automatically
set up. No need for further
setting. Please contact the
battery supplier for
installation procedure.
VSC
If selected, standard CAN
protocol will be supported.
04
Maximum
charging
current:
To configure
total charging
current for
solar and
utility
chargers.
(Max. charging
current =
utility charging
current + solar
charging
current)
60A(default)
For MPI 15KW WP model,
setting range is 1A, then
from 10A to 300A.
For MPI 12KW WP model,
setting range is 1A,then from
10A to 250A.
Increment of each click is
10A.
05
Maximum
utility charging
current
60A(default)
For MPI 15KW WP model,
setting range is 1A, then
from 10A to 300A.
For MPI 12KW WP model,
setting range is 1A, then
from 10A to 250A.
Increment of each click is
10A.
06
Maximum
discharging
current
100A(default)
For MPI 15KW WP model,
setting range is from 10A to
370A.
For MPI 12KW WP model,
setting range is from 10A to
300A.
Increment of each click is
