MPP Solar MPI 12KW WP User Manual

65
to battery should be X times cable size in the tables above. “X” indicates the number of
inverters connected in parallel.
Regarding cable size of AC input and output, please also follow the same principle.
CAUTION!! Please install a breaker at the battery side. This will ensure the inverter can
be securely disconnected during maintenance and fully protected from overcurrent of
battery.
Recommended breaker specification of battery for each inverter:
Model
One unit*
MPI 12KW WP
350A/60VDC
MPI 15KW WP
450A/60VDC
*If you want to use only one breaker at the battery side for the whole system, the rating
of the breaker should be X times current of one unit. “X” indicates the number of
inverters connected in parallel.
Recommended battery capacity
Inverter parallel
numbers
2
3
4
5
6
Battery Capacity
800AH
1200AH
1600AH
2000AH
2400AH
CAUTION! Please follow the battery charging current and voltage from battery spec to
choose the suitable battery. The wrong charging parameters will reduce the battery
lifecycle sharply.
Approximate back-up time table
Load (W)
Backup
Time
@ 48Vdc
800Ah
(min)
Backup
Time
@ 48Vdc
1200Ah
(min)
Backup
Time
@ 48Vdc
1600Ah
(min)
Backup
Time
@ 48Vdc
2000Ah
(min)
Backup
Time
@ 48Vdc
2400Ah
(min)
5,000
240
360
480
600
720
10,000
112
168
224
280
336
15,000
60
90
120
150
180
20,000
40
60
80
100
120
25,000
20
30
40
50
60
30,000
16
24
32
40
48
PV Connection
Please refer to user manual of single unit for PV Connection.
CAUTION: Each inverter should connect to PV modules separately.
