DATE
DOCUMENT NO.
CHANGE NO.
NAME
SCALE
REHNELT21.01.2020
SCHAEFERB21.01.2020
SED 6367297 000 01
1:4
1098810
22.01.2020 KLEYN
STAND.
DFTR.
CHKD.
1 1101213171M
/
DIMENSION
IN mm
EXCEPT AS
NOTED
SHEET
MATERIAL NUMBER
SERIAL NUMBER
© MASCHINENFABRIK REINHAUSEN GMBH 2018
THE REPRODUCTION, DISTRIBUTION AND UTILIZATION OF THIS DOCUMENT AS WELL AS THE COMMUNICATION OF ITS CONTENTS TO OTHERS WITHOUT EXPRESS AUTHORIZATION IS
PROHIBITED. OFFENDERS WILL BE HELD LIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THE GRANT OF A PATENT, UTILITY MODEL OR DESIGN.
A3
900,5
35.45"
Z
Z
1:1
10
.39"
120
4.72"
261
10.28"
406
15.98"
334
13.15"
240
9.45"
100
3.94"
146
5.75"
O
M8 x 20
10,5
.41"
47
1.85"
optional
MTRAB® DB200D-T mit seitlicher Zusatzbefestigung /
Maßzeichnung / DIMENSION DRAWING
MTRAB® DB200D-T WITH ADDITIONAL FASTENING POINTS
18
.71"
O
384
15.12"
M12
997
39.252"
