MR MESSKO MTRAB - Page 117

MATERIAL NUMBER
SERIAL NUMBER
DATE
DOCUMENT NO.
SHEET
CHANGE NO.
 
 
1
1/


101213190M
HUBERTHO
17.12.2018
RAEDLINGER12.12.2018 SED 6356099 000 00
1:4
1090594
SCALE
03.01.2019
KLEYN
NAME
DIMENSION
IN mm
EXCEPT AS
NOTED
STAND.
DFTR. CHKD.
© MASCHINENFABRIK REINHAUSEN GMBH 2018 THE REPRODUCTION, DISTRIBUTION AND UTILIZATION OF THIS DOCUMENT AS WELL AS THE COMMUNICATION OF ITS CONTENTS TO OTHERS WITHOUT EXPRESS AUTHORIZATION IS
PROHIBITED. OFFENDERS WILL BE HELD LIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THE GRANT OF A PATENT, UTILITY MODEL OR DESIGN.
A4
L
optional
Maß / DIMENSION DB100 DB200
L 260 [10.24"] 485 [19.10"]
MTRAB® mit Schutzgitter und Insektenschutzgitter /
Maßzeichnung / DIMENSION DRAWING
WITH PROTECTIVE GRATE AND INSECT PROTECTIVE GRATE
130 5.12"
A
A
A-A
1:1
31 1.22"
24,8
.98" O
155
6.10" O
optional
