230 Expert
Ensure that the configuration of the digital inputs and outputs is suitable for
the functions used. Otherwise, malfunctions may occur in the device and
the connected periphery.
The following information is displayed in tabular form for configuring the digi-
tal inputs and outputs. Grayed-out elements cannot be changed.
Property Options
Function Function of the digital input (I: ...) or the digital output (O: ...). You
can adjust the designation.
Signal type Select signal type: Digital input
Configuration DI: High active or low active
DO: N/O contact (NO), N/C contact (NC); Note: If the device is dis-
connected or in the event of an error, the digital outputs are always
open (no bi-stable relay).
Assembly/
channel
Channel of the DI/DO interfaces to which the function is linked.
Functions that are not linked with a channel are identified with "-".
Note the connection diagram supplied.
Table22: Configuration of the digital inputs and outputs
The operation described below is only possible if you access the visualiza-
tion using a computer. You can only change the configuration of the digital
inputs and outputs if you have a Parameter Configurator or Administrator
role.
When in delivery status, you can log in as the administrator as follows:
▪ User name: admin
▪ Password: admin
Creating a backup You need to create a backup to be able to reset the system in the event that
any incorrect configuration settings are made. To do so, proceed as follows:
1. Go to Settings > Export.
2. Go to the option Settings to export a backup copy of the current settings.
3. Select the desired Interface (USB or PC).
4. Press the Export button to start the export.
DI/DO configuration 1. Go to Settings > DI configuration/DO configuration.
2. Where necessary, select the buttons ▲ or ▼ to sort the properties in a
column alphabetically.
3. Configure the properties as desired.
4. Press the Accept button.
5. Confirm the security prompt with Yes to save the changes.
