230 Expert
Voltage-transformer circuit
You can use this parameter to set your voltage transformer's circuit. You can
select the following options:
Option Description
1 Ph phase voltage Measurement in 1-phase grid between
the conductor and neutral conductor.
3 Ph differential voltage Measurement in 3-phase grid between 2
conductors
3 Ph phase voltage Measurement in 3-phase grid between
the conductor and neutral conductor
Table28: Voltage-transformer circuit
Current-transformer circuit
You can use this parameter to set the circuit for your current transformer.
You can select the following options:
Option Description
1 Ph phase current Measurement of phase current in 1-phase
grid.
3 Ph total current Measurement of differential current in 3-
phase grid.
3 Ph phase current Measurement of phase current in 3-phase
grid.
Table29: Current-transformer circuit
Phase angle correction
You can use this parameter to set the phase angle correction for your trans-
former circuit.
9.2.1.2 Circuit examples for voltage transformers and current transformers
Below you will find different examples of circuits for voltage transformers and
current transformers and the corresponding settings.
