2 Quick Start Instructions
US FL5000 Multi-Spectrum Flame Detector 9
Figure 4 Bracket Assembly
Figure 5 FieldTerminations
3. Power
a. Ensure that all wiring is correct and unit is safe to power up.
b. Connect unit to a 24 VDC power source.
c. The unit will go through a power up delay of approximately 15 seconds. This includes LEDactivity. See 5.8
Powering the FL5000 for additional information.
d. Upon completion, Bluetooth will be activated. If a device is not connected or once a device is disconnected
from the FL5000, the Bluetooth activated state will time out within 3 minutes and revert to flame detection
mode. See 3.3 Bluetooth Connectivity for details and LEDsconfirming mode changes.
CAUTION!
While Bluetooth mode is active, the FL5000 cannot perform its safety function.
NOTE: If Bluetooth isn't needed, refer to 3.3 Bluetooth Connectivity for steps to disable Bluetooth via DIP switch. This will
enable the unit to skip the Bluetooth activation phase on start up.
