MSA ORION - Alkaline Battery Pack; To Charge the Battery Pack

•
Green
Charging is complete; the pack is fully charged and ready
for use.
•
Red Flashing
Failure mode; remove battery pack from charger.
•
LED OFF
No battery pack connected.
To Charge the Battery Pack (Vehicle Charger 10026502)
Connect the input cable assembly to the automobile lighter and the
input to the charger assembly. Align and connect charger cable plug
and battery pack charging jack using white alignment markers
located on the charger plug and the back of the battery pack.
Charger status is indicated by the LED color:
•
Yellow
Battery pack temperature is outside normal operating
charge range, an interconnect failure of plug and interface
box has occurred.
•
Allow pack to stabilize to within 0 and 40
o
.
If status continues, a battery pack failure or an
internal circuit failure has occurred.
•
Solid Red
Charging is in process.
•
Solid Green
DC supply is connected to unit.
•
Flashing Red
Charging is complete; the battery pack is fully charged
and ready for use.
Once battery pack is charged, it:
•
Can be disconnected from the charger
•
Is ready for immediate use.
Alkaline Battery Pack
•
The Orion Multigas Detector Replaceable battery pack can be
used as a:
•
Full-time battery pack or
•
Backup power source.
Operating Manual Chapter 4, Setting up the Multigas Detector
4-3
