When in the Set-up Mode, the Following Options Appear:
OPERATING BEEP
Enabling the Operating Beep causes the instrument to produce
an audible beep once every 30 seconds to correspond with the
Heartbeat indicator on the screen.
•
The Heartbeat indicator is ON solid.
•
"ON" or "OFF" appears on the screen.
1. Use the CHANGE/RESET button to switch between
"ON" and "OFF":
•
"ON" turns ON the operating beep.
•
"OFF" turns OFF the operating beep.
2. Push the ON-OFF/PAGE button to advance to the LEL set-up.
LEL SENSOR SET-UP
The LEL Sensor Set-up allows changes to be made to the
LEL exposure alarm (PEAK) and to the Autocalibration value.
º
WARNING
Incorrectly setting the autocalibration values in the
instrument could result in the instrument being incorrectly
calibrated. If using calibration gas other than the gas listed
in TABLE 5-1, the autocalibration values must be set to
match the calibration gas. Failure to do so may result in
the instrument not notifying the user of a potentially
dangerous atmosphere. Failure to follow this warning can
result in serious personal injury or death.
•
The LEL banner flashes.
1. Push the ON-OFF/PAGE button to make changes to the
LEL settings.
2. Push the CHANGE/RESET button to skip forward to the
Oxygen Set-up.
•
The LEL Banner turns ON solid.
•
The PEAK flag turns ON.
3. Push the CHANGE/RESET button to increment the exposure
alarm (PEAK) value.
4. Push the ON-OFF/PAGE button to accept the value.
Operating Manual Chapter 4, Setting up the Multigas Detector
4-9
