Appendix
J
Specifications
General
180mm (W) x 200mm (D) x 60mm (H)Dimensions
Console Port: for external DC power
Ethernet Port: 100BASETX with 802.3af (Mode A) power receiving capability
Connectivity
802.11b/g Radio port
2 x RP-TNC antenna ports (with diversity support)
IP66Enclosure Ingress
Protection (IP) rating
0ºC to 70ºC (operating)
-20ºC to 80ºC (storage)
Temperature
5 to 90% (non-condensing)Operating Humidity
Power
10-50VDCSupply Voltage
3.3WPower Dissipation
Polyfuse (resettable fuse)Protection
Ethernet Port
Auto MDI/MDIX crossoverCrossover
10 BASE-T / 100 BASE-TXAuto negotiation
Network Information
Wireless access point and WDS modesNetwork architecture
IEEE 802.3, 802.3u, 802.3af
802.1Q
Network Protocol
802.1p
Wireless Access Point User Manual87Revision B
