IllustrationProcedureStep
Screw tight the RJ45 protective
cover on the cable to the mating
jack on the switch.
4
Align the pins of the Ethernet
cable's M12 connector to the
Ethernet port of the WAP.
5
Push the connector to the port and
screw the connector into the
WAP's Ethernet port.
6
Cable tie and mount excess cable
free from any obstructions to
vehicles and machinery.
7.
2.6 Coaxial cable
Antennas are connected to the WAP's antenna ports directly or with coaxial cables. Coaxial cable length
should be kept as short as possible to minimise signal loss. It is recommended to keep cable length to less
than 10 metres.
All coaxial cable and antenna connections must be electrically insulated using self-amalgamating rubber
tape, as shown in the following procedure.
