8.7 Fuel System
8.7.1 HP fuel line and pressure pipe neck – Replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20–100 Nm
F30026582 1
Ratchet bit
F30027340 1
Plug-in open-end wrench, 19 mm
F30025897 1
Crowfoot wrench, 19 mm
F30027424 1
Ring socket, 24 mm
F30501562 1
Double-head box wrench
F30011450 1
Assembly compound (Kluthe Hakuform 30–15)
X00067260 1
Engine oil
Pressure pipe neck
(→ Spare Parts Catalog)
HP fuel line
(→ Spare Parts Catalog)
Gasket
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
WARNING
Residual pressure in high-pressure fuel system.
Risk of injury from fuel escaping under high pressure!
• After an emergency stop or engine stall, energize the engine governor for approx. 30 s.
• Always wear protective gloves and protective goggles/safety mask.
• Loosen threaded connections slowly.
WARNING
Internal tension and residual pressure in the HP fuel system.Parts can be ejected when loosening them.
Risk of injury by ejected parts!
• Only use specified tools and devices.
• Wear goggles/facial protection.
WARNING
Liquid or gaseous media, e.g. fuel, are poisonous.
Escaping vapors of highly volatile media, e.g. fuel or ether.
Risk of fatal injury through swallowing; risk of poisoning through inhalation; irritation to eyes
and skin!
• Seek medical attention immediately; do not induce vomiting.
• Do not inhale vapors or mist.
• Wear protective clothing, protective gloves, and safety glasses.
• If contact is made with skin, wash off with water and soap.
MS15054/03E 2018-07 | Fuel System | 133
TIM-ID: 0000050910 - 007
