2 Transport
2.1 Transport
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Crossbeam
T80091731 1
DANGER
Suspended load
Danger to life
• Never stand under suspended loads!
• Wear appropriate personal protective equipment.
Transport
1. Fit the transport locking device on the engine and fit the engine mounting locking devices prior to transport.
2. Always use the lifting eyes provided when transporting the engine. See installation drawings.
3. Only use suitable transport and lifting equipment.
4. Take the engine's center of gravity into account. See installation drawings.
5. The engine must only be transported in installation position: maximum permissible diagonal pull 10°.
6. Remove any loose parts on the system, engine/generator.
7. Always raise/lower the engine slowly. The lifting ropes or chains must not butt against the engine or its com-
ponents during the lifting procedure. Readjust lifting tackle as necessary.
8. Special packaging with aluminum foil: Attach engine at the lifting eyes of the bearing pedestal or transport
the engine with means of transport suitable for the load (forklift truck).
9. Secure the engine against tilting during transport. Secure, in particular, to prevent slipping and tipping when
driving up or down inclines and ramps.
Placement after transport
1. Only set down engine on a firm, level surface.
2. Make sure that the consistency and load-bearing capacity of the ground or support surface is adequate.
3. Never set the engine down on the oil pan unless this has been expressly authorized by MTU.
MS15054/03E 2018-07 | Transport | 19
TIM-ID: 0000071243 - 002
