8.11.6 Starter ‒ Installation
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 8–40 Nm
F30043446 1
Ring socket, 24 mm
F30501562 1
Lubricating grease (Molykote Longtherm 2 Plus NLGI 2)
X00057299 1
Sealing tape
50155 1
WARNING
Heavy part, risk of falling or overturning due to lack of stability.
Risk of crushing body or limbs!
• Use appropriate lifting gear and appliances.
• Wear safety shoes.
Starter ‒ Installation
1. Coat starter pinion with lubricating grease.
2. Install starter as shown in overview drawing (→ Page 163).
Connecting air starter
1. Install pressure hose.
2. Fit sealing tape on screw-fitting union. It should cover the entire thread of the union.
3. Tighten threaded adapter to specified torque using a torque wrench.
Name Size Type Lubricant Value/Standard
Union M16x1.5
(1/4"
NPT)
Tightening torque (Sealing tape) 40 Nm
4. Check if starter works properly.
MS15054/03E 2018-07 | Starting Equipment | 165
TIM-ID: 0000079958 - 001
