Sensors and actuators – Overview
Sensors and actuators – Driving end
The following overviews are also applicable to 12V engines.
Item
Name
Monitoring of
1
B3
Intake air temperature
Table 3: Sensors and actuators – Driving end
22
|
General Information
|
MS15054/03E 2018-07
TIM-ID: 0000060374 - 002
21
23
