8.11.3 Starter – Installation
Preconditions
Engine is stopped and starting disabled.
DANGER
Electric voltage supply for operation.
Danger of burns and fatal electric shock!
Make certain that the power supply to the product is switched off before starting work. Secure
against unintentional switching on!
WARNING
Heavy part, risk of falling or overturning due to lack of stability.
Risk of crushing body or limbs!
Use appropriate lifting gear and appliances.
Wear safety shoes.
Installing starter
1. Coat starter pinion with lubricating grease.
2. Install starter as per overview drawing (→ Page 160).
Connecting starter electrically
1. Connect cables in accordance with the marking.
2. Screw on nuts of connections and tighten to specified torque using a torque wrench.
a) Terminal 30 (battery connection)
Name Size Type Lubricant Value/Standard
Nut M12 Tightening torque 24.7 to 27.5 Nm
b) Terminal 50 (switching connection)
Name Size Type Lubricant Value/Standard
Nut M6 Tightening torque 5 to 7 Nm
c) Terminal 31 (negative terminal)
Name Size Type Lubricant Value/Standard
Nut M10 Tightening torque 13.5 to 15.8 Nm
3. Connect starter battery.
4. Check operation of starter.
162 | Starting Equipment |
MS15054/03E 2018-07
TIM-ID: 0000054682 - 005
