8.16 Battery-Charging Generator
8.16.1 Drive belt – Condition check
Preconditions
☑ Engine is stopped and starting disabled.
☑ Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt B Cracks on entire circumference Replace (→ Page 187)
Drive belt C Chunking
Drive belt Belt is oily, shows signs of over-
heating
MS15054/03E 2018-07 | Battery-Charging Generator | 183
TIM-ID: 0000081228 - 001
