MTU MW15406/17E - Operation; LOP controls (without Blue Line automation system)

4 Operation
4.1 LOP controls (without Blue Line automation system)
LOP – Controls
Item Color Inscription Meaning / Function
1 White F1 Function keys to control the man-machine interface.
Functions vary and are displayed on the LCD screen.
2 White F2
3 White F3
4 White F4
5 White F5
6 White ALARM ACKNOWL Pressing the button the first time stops alarm signaliza-
tion.
Pressing the button a second time acknowledges an ac-
tive alarm.
LED (spot) lights up when an alarm is active.
7 White DIM ↑ Holding down the button increases LCD background illu-
mination.
8 White DIM ↓ Holding down the button decreases LCD background illu-
mination.
MW15406/17E 2014-05 | Operation | 105
TIM-ID: 0000008860 - 004
