MTU MW15406/17E - Injection Pump - Removal and Installation

7.6.2 Injection pump – Removal and installation
Preconditions
☑Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20-100 Nm
F30026582 1
Box wrench
F30038493 1
Spider patch spanner, AF19
F30027424 1
Spider patch spanner, AF22
F30027425 1
Torque wrench, 0.5-5 Nm
0015384230 1
Grease (Kluthe Hakuform 30-10/Emulgier)
X00029933
Sealing ring
(→ Spare Parts Catalog)
Sealing ring
(→ Spare Parts Catalog)
DANGER
Rotating and moving engine parts.
Risk of crushing, danger of parts of the body being caught or pulled in!
• Before cranking the engine with starter system, make sure that there are no persons in the en-
gine's danger zone.
WARNING
Fuels are combustible.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
Preparatory steps
1. Close fuel supply line upstream of fuel filter.
2. Remove engine control system (→ Page 220).
3. Drain fuel (→ Page 170).
4. Remove charge-air pipes and all seals.
