7.7.3 Injector – Removal and installation
Preconditions
☑Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Puller
3555890163/00 1
Fuel suction device
F30378207 1
Torque wrench, 20-100 Nm
F30026582 1
Open-end wrench bit
F30025897 1
Spider patch spanner
F30027425 1
Spider patch spanner
F30027424 1
Double-head box wrench
F30011450 1
Ratchet adapter
F30027340 1
Grease (Kluthe Hakuform 30-10/Emulgier)
X00029933 1
Sealing ring
(→ Spare Parts Catalog)
Sealing ring
(→ Spare Parts Catalog)
WARNING
Fuels are combustible.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
• Never direct air jet at people.
• Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Remove cylinder head cover (→ Page 158).
2. Drain fuel (→ Page 170).
166 | Task Description | MW15406/17E 2014-05
TIM-ID: 0000004646 - 006
