Driving end A-side
Item Type of shielding Remarks
1
Driving end
Shield (A5) On valve plate
Driving end A-side
Item Type of shielding Remarks
1
Driving end
Shield (A5) On air flap control
2
Driving end
Shield (A4) On brazed-on union
3
Driving end
Shield (A5) On exhaust turbocharger flap control.
4
Driving end
Shield (A5) On exhaust turbocharger flap control.
MW15406/17E 2014-05 | Task Description | 139
TIM-ID: 0000010065 - 007
