Inclinations - standard oil system (Reference: waterline)
Number of cylinders 8 8 8 8
Longitudinal inclination, continuous max.
driving end down (option: max. operating
inclinations)
L Degrees
(°)
15* 15* 15* 15*
Longitudinal inclination, temporary max.
driving end down (option: max. operating
inclinations)
L Degrees
(°)
22.5* 22.5* 22.5* 22.5*
Longitudinal inclination, continuous max.
driving end up (option: max. operating in-
clinations)
L Degrees
(°)
0 0 0 0
Longitudinal inclination, temporary max.
driving end up (option: max. operating in-
clinations)
L Degrees
(°)
10* 10* 10* 10*
Transverse inclination continuous max.
(Option: max. operating inclinations)
L Degrees
(°)
22.5* 22.5* 22.5* 22.5*
Transverse inclination, temporary max.
(option: max. operating inclinations)
L Degrees
(°)
40* 40* 40* 40*
Capacities
Number of cylinders 8 8 8 8
Engine coolant capacity, engine side (with
cooling equipment)
R Liters - 70* - 70*
Engine oil capacity, initial filling (standard
oil system) (option: max. operating inclina-
tions)
R Liters 65 65 65 65
Oil change quantity, max. (standard oil
system) (option: max. operating inclina-
tions)
R Liters 60 60 60 60
Oil pan capacity at dipstick mark “min.”
(standard oil system) (option: max. operat-
ing inclinations)
L Liters 45 45 45 45
Oil pan capacity at dipstick mark “max.”
(standard oil system) (option: max. operat-
ing inclinations)
L Liters 55 55 55 55
Weights / main dimensions
Number of cylinders 8 8 8 8
Engine dry weight (with standard accesso-
ries installed, w/o coupling)
R kg 1790 1790 1790 1790
