MTU MW15406/17E - Page 72

CAPACITIES
Number of cylinders 12
Total engine oil capacity at initial filling (standard oil system) (Option: max. op-
erating inclinations)
R Liters 105
Oil change quantity, max. (standard oil system) (Option: max. operating incli-
nations)
R Liters 98
Oil pan capacity at dipstick mark “min.” (standard oil system) (Option: max.
operating inclinations)
L Liters 73
Oil pan capacity at dipstick mark “max.” (standard oil system) (Option: max.
operating inclinations)
L Liters 88
WEIGHTS / MAIN DIMENSIONS
Number of cylinders 12
Engine dry weight (with attached standard accessories, without coupling) R kg 2600
ACOUSTICS
Number of cylinders 12
Exhaust noise, unsilenced - BL (free-field sound pressure level Lp, 1m dis-
tance, ISO 6798, +3dB(A) tolerance)
R dB(A) 104
Engine surface noise with attenuated intake noise (filter), BL, (free-field sound-
pressure level Lp, 1m distance, ISO 6798+2dB(A) tolerance)
R dB(A) 100
72 | Technical Data | MW15406/17E 2014-05
TIM-ID: 0000010995 - 002
