User Manual
Turn the M rotary control to select the number of
start frame to store (1 - 1000)
Turn the M rotary control to select the number of end
frame to store (1 - 1000)
Save the waveform record file to the internal memory
Load the waveform record file from the memory
To use wave record function, do as follows:
(1) Push Save button.
(2) Select Type in the bottom menu, in the left menu, turn the M rotary control to
select Record.
(3) Select Mode in the bottom menu, select OFF in the right menu.
(4) In the bottom menu, select Storage as Internal.
(5) Select Mode in the bottom menu, select Record in the right menu.
(6) Select FrameSet in the bottom menu, set End frame and Interval in the right
menu.
(7) In the bottom menu, set Refresh.
(8) In the bottom menu, select Operate as Play.
(9) Select Mode in the bottom menu, select Playback in the right menu. Set
FrameSet and Playmode, select Operate as Play.
(10) To save the wave recorded, select Mode in the bottom menu, select Storage in
the right menu. Select FrameSet in the bottom menu to set the range of frames to
store, select Save in the bottom menu.
(11) To load the waveform from the internal memory, select Load in the bottom menu,
then enter the Playback of the Mode to analyze the wave.
Note: When playbacking the waveform, the sampling, trigger, or display function is
not available.
When storage medium is External, Wave Record contains two modes: OFF,
Record.
Record menu (External Storage) shows as follows:
Close wave record function
Set record menu
Turn the M rotary control to select the number of
frames to record (1 – 900,000)
Turn the M rotary control to select the interval
between recorded frames (10ms - 10s)
Record infinitely until the storage medium is full
Refresh wave during recording
Stop refreshing
To Next Page
