multicomp pro MP720025 User Manual

User Manual
80
TYPE
Model
12 bytes char
3) BYTE
Parameter name
Meaning
Value
Comment
BYTE
Data length in bit
4 bytes int
4) SIZE
Parameter name
Meaning
Value
Comment
SIZE
File size
4 bytes int
Used to check the file
integrity
5) VOLT
Parameter name
Meaning
Value
Comment
VOLT
Voltage division,
divided by 400 is
ADC resolution.
(When the source
mode is Out1&Out2,
it is the first channel
voltage division.)
4 bytes float
The value indicates voltage
(the unit is mV), such as 200
mV.
6) SAMP
Parameter name
Meaning
Value
Comment
SAMP
Sample rate
4 bytes float
The unit is Sa/s.
7) ADCB
Parameter name
Meaning
Value
Comment
ADCB
ADC bit, ADC
resolution
4 bytes int
8-bit or 12-bit
8) CHAN
Parameter name
Meaning
Value
Comment
CHAN
Number of channels
4 bytes int
1 or 2
9) VOL2
Parameter name
Meaning
Value
Comment
VOL2
Voltage division,
divided by 400 is
ADC resolution.
(When the source
mode is Out1&Out2,
it is the second
channel voltage
division.)
4 bytes float
The value indicates voltage
(the unit is mV), such as 200
mV.
2.Data
The data type is signed integer. You can determine the data type (char, short int or int) based on
the BYTE parameter. The valid range is determined by the ADCB parameter, e.g. the valid range
for 8-bit ADC is -127 to +127.
