PAGE 26 — GENERATOR SERVICE AND TROUBLESHOOTING MANUAL — REV. #0 (08/29/23)
CAMLOKS
Some generators are equipped with a camlok panel
(option). Use the camlok panel to connect external loads
to the generator.
Shown in Figure 26 are just some of the camlok panels
used on MQ Power generators.
COMPONENT IDENTIFICATION
NOTICE
Contact the Multiquip sales Dept. to order the camlok
panel required for your generator.
Figure 26. Camlok Panel Voltage Output
OK1KIT45F
DCA125SSIU4F
CAMLOK2KIT45F
DCA125SSIU4F
CAMLOK3KIT45K
DCA400SSI4F
BLK
RED
BLU
E
WHT
GRN
CAMLOK1KIT45F
DCA125SSIU4F
RED
BLK
BLU
E
WHT
GRN
RED
BLK
BLU
E
WHT
GRN
RED
BLK
BLU
E
WHT
