MACHINE COMPONENTS
37RAMMAX 1575
557068
11
12
13
14
15
OPERATION MANUAL
11 - Oil cooler
12 - Fuel tank
13 - Hydraulic tank
14 - Battery
15 - Controller (machine controller)
