RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 65
TRANSPORTING UNIT
3 3
22
1
1
555094
2.8 How to transport the Machine
• The machine can move on its own between working sites.
When moving on the working site, observe the safety
measures applicable to the working site.
When driving for long distances, 1-hour cooling breaks
after 3 hours of driving should be taken. Failing that, you
are exposed to the risk of damage to the machine for
which the manufacturer is not responsible.
• When on the road, the machine should be transported on
avehicle.
When transporting the machine on a vehicle, observe
the regulations in force in the given territory.
Make sure the transport carrier is braked and mechani-
cally secured against undesired motion with scotch
blocks (3) when loading or unloading.
The machine on the vehicle must be properly tied and
mechanically secured against longitudinal and lateral
displacement as well as against overturning (1). The
drums must be wedged with wedges (2). The maximum
permissible force of lashing the machine to the means of
transport is 2.5 t.
Centre of gravity
The centre of gravity relevant for the transport is 460 mm from
the ground and approximately in the centre of the machine, de-
pending on how full the fuel and water tanks are.
