ACTUATORS DASHBOARD COMPONENTS
40 RAMMAX 1575
557094
1
555009B
2
3
4
5
2.6 Actuators and dashboard instruments
1 - Remote control
2 - Storage area for spiral cable
3 - Display unit
4 - Ignition box
5 - Fuses
