OPERATING INFRARED REMOTE CONTROL UNIT
53RAMMAX 1575
557053
557054
1
557055
557087
2
2
OPERATION MANUAL
During operation, aim the remote control in the direc-
tion of the machine only. The cable connector (1) must
face forward.
• The remote control can lean on the operator‘s body.
The diodes of the remote control (2) must not be cov-
ered, e.g. by ngers, hand, foreign objects or dirt.
Do not aim the transmitter at reective objects (large
surfaces, light objects, other machinery, etc.).
Do not use the remote control in the protected 2-metre
zone or if there is insucient visual contact between the
machine and the operator or the remote control, unless
stated otherwise.
For optimum comfort, adjust the strap to the correct
length.
