PAGE 8 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
SPECIFICATIONS
13RAMMAX 1575
1.3 Technical Data
RAMMAX1575
EU Stage V / U.S. EPA Tier 4f
640 850
Dimension
Drum width (mm) 640 850
Weight
Operating weight of EN 500-1+A1 (CECE) kg (lb) 1340 (2950) 1440 (3170)
Operating load of EN 500-1+A1 (CECE) on front axis kg (lb) 730 (1610) 780 (1720)
Operating load of EN 500-1+A1 (CECE) on rear axis kg (lb) 610 (1340) 660 (1460)
Weight of half uid capacities kg (lb) 10 (20) 10 (20)
Operating weight of ISO 6016 kg (lb) 1350 (2980) 1450 (3200)
Maximum weight with accessories kg (lb) 1450 (3200) 1450 (3200)
Driving characteristics
Maximum transport speed km/h (MPH) 2,8 (1,7) 2,8 (1,7)
Working speed 1,4 (0,9) 1,4 (0,9)
Climbing ability without vibration % 30 30
Climbing ability with vibration % 25 25
Lateral static stability % 80 80
Lateral stability during driving without vibration % 25 25
Lateral stability during driving with vibration % 15 15
Turning radius inner (edge) mm (in) 1540 (60,6) 1440 (56,7)
Turning radius outer (contour) mm (in) 2190 (86,2) 2290 (90,2)
Type of drive - Hydrostatic
Number of driving axles - 2
Oscillation angle ° ± 7
Angle of steering ° ± 30
Steering
Type of steering - Joint
Steering control - Hydraulic
Linear hydraulic motors - 2
Engine
Manufacturer - YANMAR
Type - 3TNV80F-SPAMM
Power according to ISO 3046-1 kW (HP) 14,6 (20)
Number of cylinders - 3
Cylinder capacity cm³ (cu in) 1266 (77)
Nominal speed min¯¹ (RPM) 2400
Maximum torque Nm (ft lb)/rpm 68,4/1800
Average fuel consumption l/h (gal US/h) 3,2 (0,8)
Engines complies with emission regulations - EU Stage V, U.S. EPA Tier 4 Final
Cooling system of engine - Liquid
Brakes
Operating - Hydrostatic
Parking - Mechanical multiple-disc
Emergency - Mechanical multiple-disc
