MULTIQUIP Rammax RX1575 - Machine Components; Machine Description and Component Identification

RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 27
MACHINE COMPONENTS
36 RAMMAX 1575
557066
1
2
3
4
5
6
10
557067
7
8
9
10
2.5 Machine description
View from the right
1 - 1-point lifting eye
2 - Identication plate
3 - Drum scraper
4 - Rear bonnet closure
5 - Front bonnet closure
6 - Front sensor
View from left
7 - Articulated joint protection
8 - Cockpit cover
9 - Rear sensor
10 - 3D LF sensors (under the bonnet)
