RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 99
MAINTENANCE
1
3
2
3.6.20 Air lter cartridge replacement
• If ared ring appears on the soiling display (1) during opera-
tion of the machine, you must replace the cartridge, how-
ever at the latest after 500 engine hours. In case of work in a
very dusty environment, shorten the lter element replace-
ment intervals.
The manufacturer recommends that the elements should
not be cleaned due to adecrease in the ltration capacity
by up to 40 % and possible damaging of elements result-
ing from the cleaning.
• The air lter is located on the left side of the engine.
• Remove the wing nut (2) with the cover.
• Unscrew another winged nut.
• Remove the main cartridge of the air lter (3).
