UsingtheRouter’sWebInterface 13

3. ToallowyourroutertoconnectandsendGPSdatatoaremotelylocatedserver,seeSendingGPS
informationtoaremoteserver.
4. TosetthetimeintervalafterwhichGPSdataissent,andtoconfigurefurtherdetailsabouttheGPS
informationthatissent,seeConfiguringwhichNM
EAsentencesaresentandwhentheyaresent.
Notes:
 AllenabledsentencesareforwardedperiodicallyusingtheintervalspecifiedintheNMEAConfiguration
section.Beforeforwarding,therouterprependsanIDprefixandIDtoeachenabledNMEAsentence.The
NMEAsentencesavailablearethoseprovidedbythebuiltinreceiverwhichare:GPGGA,GPGSA,GPGSV,
GPGLL,GPRMC,GPVTG.Detaileddescriptionsofth
esu
pportedNMEAsentencesareprovidedinthe
UniversalIPATCommandsReferenceGuide.
 YoucansimultaneouslyenabletheTCPServer,TCP/UDPclientandserialportdump.
DumpingNMEAsentenceinformationtotherouter'sTCPserverport
ToconfiguretheTCPserverportwhereyoucansendtheNMEAsentences:
1. FromtheLocalConfigurationgroup,checkTCPServer.
2. InthePortfield,typetheportnumberonwhichtheTCPserverislisteningforconnections.Thedefault
is5445.Youcanuseuptofivedigits.Eachdig
ititselfmustbebetween0and9.Numbersabove65,535
areillegalastheportidentificationfieldsare16bitslongintheTCPheader.
3. IfyouwanttheservertorequestthattheremoteclientsupplyapasswordbeforetheNMEAsentences
aresent,typethatpasswordinthePasswordfield.
4. TousetheserialportforGPS,disabletheserialportclient/server.Theserialportconfigurationsettings
areusedtoco
nfigurethepor
t.Theserialportclient/servermustbedisabledtousetheserialportfor
GPS.
SendingGPSinformationtoaremoteserver
TheRemoteConfigurationallowsthedevicetoconnecttoaremoteserverusingtheIPandportinformation
foruploadingGPSdata.
1. Toallowthedevicetoconnect,checkTCP/UDP.
2. FromtheProtocoldrop‐downlist,selecttheprotocoloftheclient.
3. IntheRemoteHostfield,typetheIPaddressoftheremotehost.
4. InthePortfiel
dtypetheportnum
beroftheremotehost.
5. Ifyourremotehostrequestsapassword,typethatpasswordinthePasswordfield.Thepasswordissent
totheserverinresponse.
