UsingtheRouter’sWebInterface  28

 CheckWakeup‐on‐Call.
 SettheTimeDelayto3seconds.Youcanusethe10seconddefault.
 EnsurethatallInitStringsfieldsareempty.
 SubmitButton
ClickSubmittosavethesesettings.
CallerIDConfiguration
 EnterthestringRINGtotheCallerIDlist.
 ClicktheAddButtontosavethestringtotheCallerIDlist.
3. Afteryoucompleteallyourchanges,saveandrestart.Thedevicesavesallthesettingsandreboots.
Example3 –SetUptheEthernetRoutertoActivateonMatchingCallerIDs
Only:
1. FromtheCellularoption,selectPPPConfiguration.Setfollowingparameters:
PPPGeneral
 MakesurethatPPPisEnabled.
 MakesureDial‐on‐DemandisEnabled.
 SettheIdleTimeOuttothenumberofsecondsyoudesire.
Authentication
 YourwirelessserviceprovidermayrequireyoutohaveaseparatePPPusernameandpassword.Ifso,
enterthemhere.Ifausernameandpasswordarerequired,yourwirelessproviderprobablygave
themtoyouwhenyouactivatedyouraccount.
ModemConfiguration
 MakesureyourDialNumberisenteredcorrectly:
ForHSPAmodels,theDialNumberis*99***1#
ForEV‐DOmodels,theDialNumberis#777
Submit
• ClickSubmittosavethechanges.
2. FromtheCellularoption,selectWakeup‐on‐Call.Setthefollowingparameters:
Wakeup‐on‐CallConfiguration
 CheckWakeup‐on‐Call.
 SettheTimeDelay.Youcanusethe10seconddefault.
 EntertheInitStrings:
 SetWakeupInitString1byenteringAT+CLIP=1
 Tosavethesesettings,clickSubmit.
CallerIDConfiguration
 Enteracaller’sIDthatyouwantaddedtotheCallerIDlist.
 AddButton
