UsingtheRouter’sWebInterface 29

ClickAddtosaveeachCallerIDasitisenteredtotheCallerIDlist.
3. Afteryoucompleteallyourchanges,saveandrestart.Thedevicesavesallthesettingsandreboots
Example4 –SetUptheEthernetRoutertoActivateonIncomingSMS
Message
SettingupPPP
1. FromtheCellularoption,selectPPPConfiguration.Setthefollowingparameters:
2. InthePPPGeneralsection:
 MakesurethatPPPisDisabled(thedefault).
 MakesureDial‐on‐DemandisDisabled(thedefault).
 SettheIdleTimeOuttothenumberofsecondsyoudesire.
3. IntheAuthenticationsection,yourwirelessserviceprovidermayrequireyoutohaveaseparatePPP
UsernameandPassword.Ifso,enterthemhere.Ifusernameandpasswordarerequired,yourwireless
providerlikelygavethemtoyouwhenyoua
c
tivatedyouraccount.
4. IntheModemConfigurationsection:
 MakesureyourDialNumberisenteredcorrectly:
ForGSMmodels,theDialNumberis*99***1#
ForCDMAmodels,theDialNumberis#777
 EnteryourAPN.TheAPNisassignedbyyourwirelessserviceprovider.
 TosaveyourchangesclickSubmit.
SettingupWakeuponcall 
1. FromtheCellularoption,selectWakeUpOnCall.
2. CheckEnable.
3. SettheTimeDelay.Youcanuse10secondsasadefault.
4. EntertheInitStringssothattheintegratedcellularmodemreceivesSMS.
EnterWakeupInitString1asAT+CMGF=1
EnterWakeupInitString2asAT+CSM
S=1
EnterWa
keupInitString3asAT+CNMI=2,2,0,0,1
EnterWakeupInitString4asat^scfg=”URC/DstIfc”,mdm
5. Tosavethesesettings,clickSubmit.
SettingupSMS
1. FromtheCellularoption,selectWakeUpOnCall.
2. IntheOnSMSgroup,checkEnabled.
3. InthemessagefieldtypeanSMS.TheSMSmessagestringmustnotcontainanyspacesbetweenwords.
WhentheconfiguredstringmatchestheSMSmessagestring,itactivatestheWakeup‐on‐Callfeature
4. ClickAdd.
